All Dimensions for the Opel/Vauxhall Vivaro (2019-on)

If you're looking for the specific dimensions of the Peugeot Expert, you're in the right place. In this article, I'll go over the exact interior dimensions (how tall, how wide, and spacious).

CENTIMETERS

  • The interior dimensions (length) of the Opel/Vauxhall Vivaro cargo space is 2162mm (L1), 2512mm (L2), and 2862mm (L3).
  • The interior width of the is 1628mm and the exterior width is 2204mm.
  • The interior height of the Vivaro is 1397mm (H1), 1397mm (H2), and 1397mm (H3).
  • The wheelbase lengths are 2925mm (SWB), 3275mm (MWB), and 3275mm (LWB).
  • The width between the wheel arches on this model is 1258mm.

INCHES

  • The interior dimensions (length) of the Opel/Vauxhall Vivaro cargo space is 85.1" (L1), 98.9" (L2), and 112.7" (L3).
  • The interior width of the is 64.1" and the exterior width is 86.8".
  • The interior height of the Vivaro is 55" (H1), 55" (H2), and 55" (H3).
  • The wheelbase lengths are 115.2" (SWB), 128.9" (MWB), and 128.9" (LWB).
  • The width between the wheel arches on this model is 49.5".

Are these dimensions right for you?

Correct dimensions for: Citroën Jumpy Citroën Dispatch Toyota ProAce Citroën SpaceTourer (passenger) Peugeot Traveller (passenger) Peugeot Expert Production years: 2019 - present Generation: 3 Type of van: com_panel

Dimensions in tables

Outside dimensions of the Vivaro:

Exterior L1 L2 L3 Width
Exterior length (mm) 4609 4959 5309 2204
Exterior length (inch) 181.5 195.2 209 86.8

All models of the Opel/Vauxhall Vivaro have the same interior and exterior width: 64.1" or 1628mm (interior); and 86.8" or 2204mm (exterior).

Interior dimensions of the Vivaro:

Inside dimensions L1 L2 L3 Width
Interior length (mm) 2162 2512 2862 1628
Interior length (inch) 85.1 98.9 112.7 64.1

The double cab model has:

  • a total load length of 2,365mm or 93"
  • an effective load length at half height (upper half) of 1,700mm or 67"

Extra load length: Moduwork

The Peugeot Expert comes with a Moduwork feature, which allows you to load piping and planks through the bulkhead under the passenger seat. For the Moduwork feature, the internal load length is as follows:
[- L1 - 3,325mm]

  • L2 - 3,674mm
  • L3 - 4,024mm

Maximum floor surface:

Max. floor area L1 L2 L3
Square meters (m2) 3.5 4.1 4.7
Square feet (ft2) 37.9 44 50.2

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1258mm, or 49.5".

Opel/Vauxhall Vivaro roof height:

Roof in millimeters H1 H2 H3
Interior height (mm) 1397 1397 1397
Exterior height (mm) 1905 1895 1935
Roof in inches H1 H2 H3
Interior height (inch) 55 55 55
Exterior height (inch) 75 74.6 76.2

Wheelbase distance:

Wheelbase short (SWB) medium (MWB) long (LWB)
Wheelbase length (mm) 2925 3275 3275
Wheelbase length (inch) 115 129 129

Door measurements:

Doors Side door Rear door
Door width (mm) 745 1628
Door height (mm) 1238 1220
Side door Rear door
Door width (inch) 29.3 64.1
Door height (inch) 48.7 48

Load floor height:

Variant Metric (mm) Inches
L1 - Compact 626 24.7"
L2 - Standard 613 24.1"
L3 - Long 633 24.9"

History of this model
