The Exact Dimensions for the Peugeot Expert (2016-on)
If you're looking for the specific dimensions of the Peugeot Expert, you're in the right place. In this article, I'll go over the exact interior dimensions (how tall, how wide, and spacious).
- The interior dimensions (length) of the Peugeot Expert cargo space is 2162mm (L1), 2512mm (L2), and 2862mm (L3).
- The interior width of the is 1628mm and the exterior width is 2204mm.
- The interior height of the Expert is 1397mm (H1), 1397mm (H2), and 1397mm (H3).
- The wheelbase lengths are 2925mm (SWB), 3275mm (MWB), and 3275mm (LWB).
- The width between the wheel arches on this model is 1258mm.
- The interior dimensions (length) of the Peugeot Expert cargo space is 85.1" (L1), 98.9" (L2), and 112.7" (L3).
- The interior width of the is 64.1" and the exterior width is 86.8".
- The interior height of the Expert is 55" (H1), 55" (H2), and 55" (H3).
- The wheelbase lengths are 115.2" (SWB), 128.9" (MWB), and 128.9" (LWB).
- The width between the wheel arches on this model is 49.5".
Are these dimensions right for you?Correct dimensions for: Citroën Jumpy Citroën Dispatch Toyota ProAce Citroën SpaceTourer (passenger) Peugeot Traveller (passenger) Opel/Vauxhall Vivaro (from 2019 onwards) Production years: 2016 - present Generation: 3 Type of van: com_panel
Dimensions in tables
Outside dimensions of the Expert:
|Exterior length (mm)||4609||4959||5309||2204|
|Exterior length (inch)||181.5||195.2||209||86.8|
All models of the Peugeot Expert have the same interior and exterior width: 64.1" or 1628mm (interior); and 86.8" or 2204mm (exterior).
Interior dimensions of the Expert:
|Interior length (mm)||2162||2512||2862||1628|
|Interior length (inch)||85.1||98.9||112.7||64.1|
The double cab model has:
- a total load length of 2,365mm or 93"
- an effective load length at half height (upper half) of 1,700mm or 67"
Extra load length: Moduwork
The Peugeot Expert comes with a Moduwork feature, which allows you to load piping and planks through the bulkhead under the passenger seat. For the Moduwork feature, the internal load length is as follows:
- [L1 - 3,325mm]
- L2 - 3,674mm
- L3 - 4,024mm
Maximum floor surface:
|Max. floor area||L1||L2||L3|
|Square meters (m2)||3.5||4.1||4.7|
|Square feet (ft2)||37.9||44||50.2|
Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1258mm, or 49.5".
Peugeot Expert roof height:
|Roof in millimeters||H1||H2||H3|
|Interior height (mm)||1397||1397||1397|
|Exterior height (mm)||1905||1895||1935|
|Roof in inches||H1||H2||H3|
|Interior height (inch)||55||55||55|
|Exterior height (inch)||75||74.6||76.2|
|Wheelbase||short (SWB)||medium (MWB)||long (LWB)|
|Wheelbase length (mm)||2925||3275||3275|
|Wheelbase length (inch)||115||129||129|
|Doors||Side door||Rear door|
|Door width (mm)||745||1628|
|Door height (mm)||1238||1220|
|Side door||Rear door|
|Door width (inch)||29.3||64.1|
|Door height (inch)||48.7||48|
Load floor height:
|L1 - Compact||626||24.7"|
|L2 - Standard||613||24.1"|
|L3 - Long||633||24.9"|
