CENTIMETERS

• The interior dimensions (length) of the Volkswagen Transporter - T5 cargo space is 2353mm (L1).
• The interior width of the is 1692mm and the exterior width is 1900mm.
• The interior height of the Transporter - T5 is 1410mm (H1).
• The wheelbase lengths are 3000mm (SWB), and 3400mm (LWB).
• The width between the wheel arches on this model is 1244mm.

INCHES

• The interior dimensions (length) of the Volkswagen Transporter - T5 cargo space is 92.6" (L1).
• The interior width of the is 66.6" and the exterior width is 74.8".
• The interior height of the Transporter - T5 is 55.5" (H1).
• The wheelbase lengths are 118.1" (SWB), and 133.9" (LWB).
• The width between the wheel arches on this model is 49".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Transporter - T5:

Exterior	L1	L3	Width
Exterior length (mm)	4892	5292	1900
Exterior length (inch)	192.6	208.3	74.8

• H1=2,176mm medium height, SWB
• H3=standard and medium height available for LWB

All models of the Volkswagen Transporter - T5 have the same interior and exterior width: 66.6" or 1692mm (interior); and 74.8" or 1900mm (exterior).

Interior dimensions of the Transporter - T5:

Inside dimensions	L1	L3	Width
Interior length (mm)	2353	2753	1692
Interior length (inch)	92.6	108.4	66.6

• H1=1,626mm medium height, SWB
• H3=standard and medium height available for LWB

Maximum floor surface:

Max. floor area	L1	L3
Square meters (m2)	4	4.7
Square feet (ft2)	42.9	50.1

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1244mm, or 49".

Volkswagen Transporter - T5 roof height:

Roof in millimeters	H1	H3
Interior height (mm)	1410	1940
Exterior height (mm)	1990	2476
Roof in inches	H1	H3
Interior height (inch)	55.5	76.4
Exterior height (inch)	78.3	97.5

Wheelbase distance:

Wheelbase	short (SWB)	long (LWB)
Wheelbase length (mm)	3000	3400
Wheelbase length (inch)	118	134

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x	x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	1020
Door height (mm)	1284
Door width (inch)	40.2
Door height (inch)	50.6

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear tailgate door measurements

Tailgate door	Regular
Door width (mm)	1486
Door height (mm)	1305
Door width (inch)	58.5
Door height (inch)	51.4

Miscellaneous dimensions:

Dimension	mm	inch
Front overhang	896	35.3
Rear overhang	996	39.2

Other resources

• Besides this page, we've also created a resource containing the tightening torque spec settings of the VW Transporter T5.
