CENTIMETERS

• The interior dimensions (length) of the Toyota Sienna 3 XL cargo space is 2438mm (L1).
• The interior width of the is and the exterior width is 1985mm.
• The interior height of the Sienna 3 XL is 993mm (H1), 1008mm (H2), and 973mm (H3).
• The wheelbase lengths are 3030mm (SWB).
• The width between the wheel arches on this model is 1292mm.

INCHES

• The interior dimensions (length) of the Toyota Sienna 3 XL cargo space is 96" (L1).
• The interior width of the is and the exterior width is 78.1".
• The interior height of the Sienna 3 XL is 39.1" (H1), 39.7" (H2), and 38.3" (H3).
• The wheelbase lengths are 119.3" (SWB).
• The width between the wheel arches on this model is 50.9".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Sienna 3 XL:

Exterior	L1
Exterior length (mm)	5085	1985
Exterior length (inch)	200.2	78.1

All models of the Toyota Sienna 3 XL have the same interior and exterior width: 78.1" or 1985mm (exterior).

Interior dimensions of the Sienna 3 XL:

Inside dimensions	L1
Interior length (mm)	2438
Interior length (inch)	96

L1=you tube video
H1=front seats; Headroom dimensions with moonroof model
H2=middle seats; Headroom dimensions with moonroof model
H3=rear seats; Headroom dimensions with moonroof model
Width between wheelarches=you tube video

Maximum floor surface:

Max. floor area	L1
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1292mm, or 50.9".

Toyota Sienna 3 XL roof height:

Roof in millimeters	H1	H2	H3
Interior height (mm)	993	1008	973
Exterior height (mm)	1765
Roof in inches	H1	H2	H3
Interior height (inch)	39.1	39.7	38.3
Exterior height (inch)	69.5

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	3030
Wheelbase length (inch)	119

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	165	6.5
Front track	1720	67.7
Rear track	1720	67.7
