CENTIMETERS

• The interior dimensions (length) of the Toyota Sienna 1 XL10 cargo space is 2202mm (L1), and 1379mm (L2).
• The interior width of the is 1209mm and the exterior width is 1865mm.
• The interior height of the Sienna 1 XL10 is 1044mm (H1).
• The wheelbase lengths are 2900mm (SWB).

INCHES

• The interior dimensions (length) of the Toyota Sienna 1 XL10 cargo space is 86.7" (L1), and 54.3" (L2).
• The interior width of the is 47.6" and the exterior width is 73.4".
• The interior height of the Sienna 1 XL10 is 41.1" (H1).
• The wheelbase lengths are 114.2" (SWB).

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Sienna 1 XL10:

Exterior	L1	L2	Width
Exterior length (mm)	4930	1865
Exterior length (inch)	194.1	73.4

All models of the Toyota Sienna 1 XL10 have the same interior and exterior width: 47.6" or 1209mm (interior); and 73.4" or 1865mm (exterior).

Interior dimensions of the Sienna 1 XL10:

Inside dimensions	L1	L2	Width
Interior length (mm)	2202	1379	1209
Interior length (inch)	86.7	54.3	47.6

L1=Cargo Area Length @ Floor to Seat 1
L2=Cargo Area Length @ Floor to Seat 2
H1=Cargo Box (Area) Height
Width min (at floor)=Cargo Box Width @ Wheelhousings

Maximum floor surface:

Max. floor area	L1	L2
Square meters (m2)	2.7	1.7
Square feet (ft2)	28.7	17.9

Please note that this is an indication and does not take into account the wheel arches.

Toyota Sienna 1 XL10 roof height:

Roof in millimeters	H1
Interior height (mm)	1044
Exterior height (mm)	1710
Roof in inches	H1
Interior height (inch)	41.1
Exterior height (inch)	67.3

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	2900
Wheelbase length (inch)	114

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear doors:

Barn door measurements

Rear barn door	Regular
Door width (mm)	1245
Door height (mm)	947
Door width (inch)	49
Door height (inch)	37.3

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	150	5.9
Front track	1565	61.6
Rear track	1610	63.4
