CENTIMETERS

• The interior dimensions (length) of the Toyota HiAce 5 cargo space is 2335mm (L1).
• The interior width of the is 1650mm and the exterior width is 1800mm.
• The interior height of the HiAce 5 is 1420mm (H1).
• The wheelbase lengths are 2985mm (SWB), and 3430mm (LWB).

INCHES

• The interior dimensions (length) of the Toyota HiAce 5 cargo space is 91.9" (L1).
• The interior width of the is 65" and the exterior width is 70.9".
• The interior height of the HiAce 5 is 55.9" (H1).
• The wheelbase lengths are 117.5" (SWB), and 135" (LWB).

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the HiAce 5:

Exterior	L1	L3	Width
Exterior length (mm)	4715	5160	1800
Exterior length (inch)	185.6	203.1	70.9

All models of the Toyota HiAce 5 have the same interior and exterior width: 65" or 1650mm (interior); and 70.9" or 1800mm (exterior).

Interior dimensions of the HiAce 5:

Inside dimensions	L1	L3	Width
Interior length (mm)	2335	2780	1650
Interior length (inch)	91.9	109.4	65

Maximum floor surface:

Max. floor area	L1	L3
Square meters (m2)	3.9	4.6
Square feet (ft2)	41.5	49.4

Please note that this is an indication and does not take into account the wheel arches.

Toyota HiAce 5 roof height:

Roof in millimeters	H1	H3
Interior height (mm)	1420
Exterior height (mm)	2000	1995
Roof in inches	H1	H3
Interior height (inch)	55.9
Exterior height (inch)	78.7	78.5

Wheelbase distance:

Wheelbase	short (SWB)	long (LWB)
Wheelbase length (mm)	2985	3430
Wheelbase length (inch)	118	135

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
	x		x

Side doors measurements:

Hinged side door measurements

Hinged side door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear doors:

Rear tailgate door measurements

Tailgate door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	5.5	18
Long wheelbase	6.2	20.3

Miscellaneous dimensions:

Dimension	mm	inch
Front track	1560	61.4
Rear track	1540	60.6
