CENTIMETERS

• The interior dimensions (length) of the Peugeot Partner II cargo space is 1800mm (L1).
• The interior width of the is 1380mm and the exterior width is
• The interior height of the Partner II is 1250mm (H1).
• The wheelbase lengths are 2728mm (SWB).
• The width between the wheel arches on this model is 1230mm.

INCHES

• The interior dimensions (length) of the Peugeot Partner II cargo space is 70.9" (L1).
• The interior width of the is 54.3" and the exterior width is
• The interior height of the Partner II is 49.2" (H1).
• The wheelbase lengths are 107.4" (SWB).
• The width between the wheel arches on this model is 48.4".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Partner II:

Exterior	L1	L3	Width
Exterior length (mm)	4380	4628
Exterior length (inch)	172.4	182.2

All models of the Peugeot Partner II have the same interior and exterior width: 54.3" or 1380mm (interior); and .

Interior dimensions of the Partner II:

Inside dimensions	L1	L3	Width
Interior length (mm)	1800	2050	1380
Interior length (inch)	70.9	80.7	54.3

Maximum floor surface:

Max. floor area	L1	L3
Square meters (m2)	2.5	2.8
Square feet (ft2)	26.7	30.5

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1230mm, or 48.4".

Peugeot Partner II roof height:

Roof in millimeters	H1	H3
Interior height (mm)	1250
Exterior height (mm)	1801	1828
Roof in inches	H1	H3
Interior height (inch)	49.2
Exterior height (inch)	70.9	72

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	2728
Wheelbase length (inch)	107

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door	Regular	Large
Door width (mm)	640	737
Door height (mm)	1100	1192
Door width (inch)	25.2	29
Door height (inch)	43.3	46.9

Rear doors:

Barn door measurements

Rear barn door	Regular
Door width (mm)	1250
Door height (mm)	1148
Door width (inch)	49.2
Door height (inch)	45.2

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	11	36.1

Miscellaneous dimensions:

Dimension	mm	inch
Front track	1505	59.3
Rear track	1554	61.2
