The Exact Dimensions of the Peugeot Expert (2007-2016)

CENTIMETERS

  • The interior dimensions (length) of the Peugeot Expert cargo space is 2254mm (L1), and 2584mm (L2).
  • The interior width of the is 1600mm and the exterior width is 2194mm.
  • The interior height of the Expert is 1449mm (H1), and 1449mm (H2).
  • The wheelbase lengths are 3000mm (SWB), and 3122mm (LWB).
  • The width between the wheel arches on this model is 1245mm.

INCHES

  • The interior dimensions (length) of the Peugeot Expert cargo space is 88.7" (L1), and 101.7" (L2).
  • The interior width of the is 63" and the exterior width is 86.4".
  • The interior height of the Expert is 57" (H1), and 57" (H2).
  • The wheelbase lengths are 118.1" (SWB), and 122.9" (LWB).
  • The width between the wheel arches on this model is 49".

Are these dimensions right for you?

Correct dimensions for: Citroën Jumpy Citroën Dispatch Fiat Scudo Toyota ProAce (from 2013 onwards) Production years: 2007 - 2016 Generation: 2 Type of van: com_panel

Dimensions in tables

Outside dimensions of the Expert:

Exterior L1 L2 Width
Exterior length (mm) 3805 5135 2194
Exterior length (inch) 149.8 202.2 86.4

All models of the Peugeot Expert have the same interior and exterior width: 63" or 1600mm (interior); and 86.4" or 2194mm (exterior).

Interior dimensions of the Expert:

Inside dimensions L1 L2 Width
Interior length (mm) 2254 2584 1600
Interior length (inch) 88.7 101.7 63

Maximum floor surface:

Max. floor area L1 L2
Square meters (m2) 3.6 4.1
Square feet (ft2) 38.8 44.5

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1245mm, or 49".

Peugeot Expert roof height:

Roof in millimeters H1 H2
Interior height (mm) 1449 1449
Exterior height (mm) 1942 1942
Roof in inches H1 H2
Interior height (inch) 57 57
Exterior height (inch) 76.5 76.5

Wheelbase distance:

Wheelbase short (SWB) long (LWB)
Wheelbase length (mm) 3000 3122
Wheelbase length (inch) 118 123

Door measurements:

Doors Side door Rear door
Door width (mm) 924 1237
Door height (mm) 1293 1272
Side door Rear door
Door width (inch) 36.4 48.7
Door height (inch) 50.9 50.1

Load floor height:

Variant Metric (mm) Inches
Unloaded 604 23.8"
Loaded 562 22.1"
Air suspension - Unloaded 499 19.65"
Air suspension - Loaded 490 19.3"
