Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the Mercedes Mercedes-Benz Vito 3 W447 cargo space is 2677mm (L1).
• The interior width of the is and the exterior width is 1928mm.
• The interior height of the Mercedes-Benz Vito 3 W447 is 1397mm (H1).
• The wheelbase lengths are 3200mm (SWB), and 3430mm (LWB).
• The width between the wheel arches on this model is 1270mm.

INCHES

• The interior dimensions (length) of the Mercedes Mercedes-Benz Vito 3 W447 cargo space is 105.4" (L1).
• The interior width of the is and the exterior width is 75.9".
• The interior height of the Mercedes-Benz Vito 3 W447 is 55" (H1).
• The wheelbase lengths are 126" (SWB), and 135" (LWB).
• The width between the wheel arches on this model is 50".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Mercedes-Benz Vito 3 W447:

Exterior	L1	L3
Exterior length (mm)	4895	5140	5370	1928
Exterior length (inch)	192.7	202.4	211.4	75.9

All models of the Mercedes Mercedes-Benz Vito 3 W447 have the same interior and exterior width: 75.9" or 1928mm (exterior).

Interior dimensions of the Mercedes-Benz Vito 3 W447:

Inside dimensions	L1	L3
Interior length (mm)	2677	2908
Interior length (inch)	105.4	114.5

Maximum floor surface:

Max. floor area	L1	L3
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1270mm, or 50".

Mercedes Mercedes-Benz Vito 3 W447 roof height:

Roof in millimeters	H1	H3
Interior height (mm)	1397
Exterior height (mm)	1880	1958
Roof in inches	H1	H3
Interior height (inch)	55
Exterior height (inch)	74	77.1

Wheelbase distance:

Wheelbase	short (SWB)	long (LWB)
Wheelbase length (mm)	3200	3430
Wheelbase length (inch)	126	135

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x	x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	960
Door height (mm)	1252
Door width (inch)	37.8
Door height (inch)	49.3

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear tailgate door measurements

Tailgate door	Regular
Door width (mm)	1392
Door height (mm)	1260
Door width (inch)	54.8
Door height (inch)	49.6

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	11.8	38.7

Miscellaneous dimensions:

Dimension	mm	inch
Front overhang	895	35.2
Rear overhang	1044	41.1
Front track	1666	65.6
Rear track	1646	64.8
