Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the Mercedes Mercedes-Benz Vito 2 W639 cargo space is 1650mm (L1), 1650mm (L2), and 1650mm (L3).
• The interior width of the is 1630mm and the exterior width is
• The interior height of the Mercedes-Benz Vito 2 W639 is 1333mm (H1), 1333mm (H2), and 1411mm (H3).
• The wheelbase lengths are 3200mm (SWB), 3200mm (MWB), and 3430mm (LWB).
• The width between the wheel arches on this model is 1270mm.

INCHES

• The interior dimensions (length) of the Mercedes Mercedes-Benz Vito 2 W639 cargo space is 65" (L1), 65" (L2), and 65" (L3).
• The interior width of the is 64.2" and the exterior width is
• The interior height of the Mercedes-Benz Vito 2 W639 is 52.5" (H1), 52.5" (H2), and 55.6" (H3).
• The wheelbase lengths are 126" (SWB), 126" (MWB), and 135" (LWB).
• The width between the wheel arches on this model is 50".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Mercedes-Benz Vito 2 W639:

Exterior	L1	L2	L3	Width
Exterior length (mm)	5008	5008	5283
Exterior length (inch)	197.2	197.2	208

All models of the Mercedes Mercedes-Benz Vito 2 W639 have the same interior and exterior width: 64.2" or 1630mm (interior max); and .

Interior dimensions of the Mercedes-Benz Vito 2 W639:

Inside dimensions	L1	L2	L3	Width
Interior length (mm)	1650	1650	1650	1630
Interior length (inch)	65	65	65	64.2

Maximum floor surface:

Max. floor area	L1	L2	L3
Square meters (m2)	2.7	2.7	2.7
Square feet (ft2)	28.9	28.9	28.9

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1270mm, or 50".

Mercedes Mercedes-Benz Vito 2 W639 roof height:

Roof in millimeters	H1	H2	H3
Interior height (mm)	1333	1333	1411
Exterior height (mm)	1902	1902	1900
Roof in inches	H1	H2	H3
Interior height (inch)	52.5	52.5	55.6
Exterior height (inch)	74.9	74.9	74.8

Wheelbase distance:

Wheelbase	short (SWB)	medium (MWB)	long (LWB)
Wheelbase length (mm)	3200	3200	3430
Wheelbase length (inch)	126	126	135

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x	x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	985
Door height (mm)	1259
Door width (inch)	38.8
Door height (inch)	49.6

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear tailgate door measurements

Tailgate door	Regular
Door width (mm)	1396
Door height (mm)	1264
Door width (inch)	55
Door height (inch)	49.8

Load floor height:

Height	Metric (mm)	Inches
Minimal loading sill height	560	22
Maximum loading sill height	562	22.1

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	11.8	38.7
Medium wheelbase	11.8	38.7
Long wheelbase	12.5	41

Miscellaneous dimensions:

Dimension	mm	inch
Rear overhang	1010	39.8
Front track	1630	64.2
Rear track	1630	64.2
