CENTIMETERS

• The interior dimensions (length) of the Ford Transit Custom Nugget cargo space is 2000mm (L1).
• The interior width of the is 1381mm and the exterior width is 1986mm.
• The interior height of the Transit Custom Nugget is 2420mm (H1), 830mm (H2), and 930mm (H3).
• The wheelbase lengths are 2933mm (SWB), and 3300mm (LWB).

INCHES

• The interior dimensions (length) of the Ford Transit Custom Nugget cargo space is 78.7" (L1).
• The interior width of the is 54.4" and the exterior width is 78.2".
• The interior height of the Transit Custom Nugget is 95.3" (H1), 32.7" (H2), and 36.6" (H3).
• The wheelbase lengths are 115.5" (SWB), and 129.9" (LWB).

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Transit Custom Nugget:

Exterior	L1	Width
Exterior length (mm)	4972	5339	1986
Exterior length (inch)	195.7	210.2	78.2

All models of the Ford Transit Custom Nugget have the same interior and exterior width: 54.4" or 1381mm (interior); and 78.2" or 1986mm (exterior).

Interior dimensions of the Transit Custom Nugget:

Inside dimensions	L1	Width
Interior length (mm)	2000	1381
Interior length (inch)	78.7	54.4

Maximum floor surface:

Max. floor area	L1
Square meters (m2)	2.8
Square feet (ft2)	29.7

Please note that this is an indication and does not take into account the wheel arches.

Ford Transit Custom Nugget roof height:

Roof in millimeters	H1	H2	H3
Interior height (mm)	2420	830	930
Exterior height (mm)	2085	2800
Roof in inches	H1	H2	H3
Interior height (inch)	95.3	32.7	36.6
Exterior height (inch)	82.1	110.2

Please note! This is a camper van. The heights are specified as follows:

• H1 - 2420/1850mm Interior headroom kitchen/ living area
• H2 - Interior height above height bed
• H3 - Interior height between bed surface of seat bench and bottom side bed roof

Wheelbase distance:

Wheelbase	short (SWB)	long (LWB)
Wheelbase length (mm)	2933	3300
Wheelbase length (inch)	115	130

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	1030
Door height (mm)	1321
Door width (inch)	40.6
Door height (inch)	52

Rear doors:

Barn door measurements

Rear barn door	Regular
Door width (mm)	1404
Door height (mm)	1347
Door width (inch)	55.3
Door height (inch)	53

Please note: door dimensions are taken from the Ford Transit Custom base model and are unverified.

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)	Wall-to-wall (m)	Wall-to-wall (ft)
Short wheelbase	11.6	38.1	12.2	40
Long wheelbase	12.8	42	13.4	44

Miscellaneous dimensions:

Dimension	mm	inch
Front track	1560	61.4
Rear track	1567	61.7
