What are the Dimensions for the Toyota HiAce 6 (2019-on)?

CENTIMETERS

  • The interior dimensions (length) of the Toyota HiAce 6 cargo space is 2745mm (L1).
  • The interior width of the is 1775mm and the exterior width is 1950mm.
  • The interior height of the HiAce 6 is 1315mm (H1).
  • The wheelbase lengths are 3210mm (SWB), and 3860mm (LWB).
  • The width between the wheel arches on this model is 1268mm.

INCHES

  • The interior dimensions (length) of the Toyota HiAce 6 cargo space is 108.1" (L1).
  • The interior width of the is 69.9" and the exterior width is 76.8".
  • The interior height of the HiAce 6 is 51.8" (H1).
  • The wheelbase lengths are 126.4" (SWB), and 152" (LWB).
  • The width between the wheel arches on this model is 49.9".

Are these dimensions right for you?

Production years: 2019 - present Generation: 6 Type of van: cargo Body style: Panel Also known as: Toyota GranAce (Japan)[ Toyota Commuter (Thailand) Toyota Majesty (Thailand and Brunei)[ Toyota Granvia (Taiwan, Australia, Vietnam and UAE)[ Toyota Quantum (South Africa)[

Dimensions in tables

Outside dimensions of the HiAce 6:

Exterior L1 L3 Width
Exterior length (mm) 5265 5915 1950
Exterior length (inch) 207.3 232.9 76.8

HI,H3 =Unladen vehicle

All models of the Toyota HiAce 6 have the same interior and exterior width: 69.9" or 1775mm (interior); and 76.8" or 1950mm (exterior).

Interior dimensions of the HiAce 6:

Inside dimensions L1 L3 Width
Interior length (mm) 2745 3395 1775
Interior length (inch) 108.1 133.7 69.9

Width between wheelarches = 2021 Model

Maximum floor surface:

Max. floor area L1 L3
Square meters (m2) 4.9 6
Square feet (ft2) 52.4 64.9

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1268mm, or 49.9".

Toyota HiAce 6 roof height:

Roof in millimeters H1 H3
Interior height (mm) 1315 1610
Exterior height (mm) 1990 2280
Roof in inches H1 H3
Interior height (inch) 51.8 63.4
Exterior height (inch) 78.3 89.8

Wheelbase distance:

Wheelbase short (SWB) long (LWB)
Wheelbase length (mm) 3210 3860
Wheelbase length (inch) 126 152

Door measurements:

Available door options:

Side doors Rear doors
Slide Hinged Barn Tailgate
x x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Miscellaneous dimensions:

Dimension mm inch
Ground clearance unladen 180 7.1
Front track 1675 65.9
Rear track 1670 65.7
