CENTIMETERS

• The interior dimensions (length) of the Toyota ProAce City cargo space is 1820mm (L1), and 2170mm (L2).
• The interior width of the is 1714mm and the exterior width is 1831mm.
• The interior height of the ProAce City is 1305mm (H1), and 1550mm (H2).
• The wheelbase lengths are 2755mm (SWB), and 3105mm (MWB).
• The width between the wheel arches on this model is 1230mm.

INCHES

• The interior dimensions (length) of the Toyota ProAce City cargo space is 71.7" (L1), and 85.4" (L2).
• The interior width of the is 67.5" and the exterior width is 72.1".
• The interior height of the ProAce City is 51.4" (H1), and 61" (H2).
• The wheelbase lengths are 108.5" (SWB), and 122.2" (MWB).
• The width between the wheel arches on this model is 48.4".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the ProAce City:

Exterior	L1	L2	Width
Exterior length (mm)	4390	4740	1831
Exterior length (inch)	172.8	186.6	72.1

H1=L1H1
H2=L2H1
H3=L1H2
H4=L2H2

All models of the Toyota ProAce City have the same interior and exterior width: 67.5" or 1714mm (interior max); and 72.1" or 1831mm (exterior).

Interior dimensions of the ProAce City:

Inside dimensions	L1	L2	Width
Interior length (mm)	1820	2170	1714
Interior length (inch)	71.7	85.4	67.5

Maximum floor surface:

Max. floor area	L1	L2
Square meters (m2)	3.1	3.7
Square feet (ft2)	33.6	40

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1230mm, or 48.4".

Toyota ProAce City roof height:

Roof in millimeters	H1	H2	H3	H4
Interior height (mm)	1305	1550
Exterior height (mm)	1845	1880	2100	2125
Roof in inches	H1	H2	H3	H4
Interior height (inch)	51.4	61
Exterior height (inch)	72.6	74	82.7	83.7

Wheelbase distance:

Wheelbase	short (SWB)	medium (MWB)
Wheelbase length (mm)	2755	3105
Wheelbase length (inch)	108	122

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	700
Door height (mm)	1175
Door width (inch)	27.6
Door height (inch)	46.3

Rear doors:

Barn door measurements

Rear barn door	Regular	H2
Door width (mm)	1231
Door height (mm)	1250	1455
Door width (inch)	48.5
Door height (inch)	49.2	57.3

Load floor height:

Height	Metric (mm)	Inches
Minimal loading sill height	545	21.5

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	11.3	37.1
Medium wheelbase	12.5	41

Miscellaneous dimensions:

Dimension	mm	inch
Front overhang	892	35.1
Rear overhang	726	28.6
Front track	1553	61.1
Rear track	1567	61.7
