Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the Nissan Nissan NV250 cargo space is 1731mm (L1), 2115mm (L2), and 1432mm (L3).
• The interior width of the is and the exterior width is 1829mm.
• The interior height of the Nissan NV250 is 1251mm (H1), 1252mm (H2), and 1154mm (H3).
• The wheelbase lengths are 2697mm (SWB), and 3081mm (MWB).
• The width between the wheel arches on this model is 1218mm.

INCHES

• The interior dimensions (length) of the Nissan Nissan NV250 cargo space is 68.1" (L1), 83.3" (L2), and 56.4" (L3).
• The interior width of the is and the exterior width is 72".
• The interior height of the Nissan NV250 is 49.3" (H1), 49.3" (H2), and 45.4" (H3).
• The wheelbase lengths are 106.2" (SWB), and 121.3" (MWB).
• The width between the wheel arches on this model is 48".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Nissan NV250:

Exterior	L1	L2	L3
Exterior length (mm)	4282	4666	1829
Exterior length (inch)	168.6	183.7	72

All models of the Nissan Nissan NV250 have the same interior and exterior width: 72" or 1829mm (exterior).

Interior dimensions of the Nissan NV250:

Inside dimensions	L1	L2	L3
Interior length (mm)	1731	2115	1432
Interior length (inch)	68.1	83.3	56.4

L3=for crew van

Maximum floor surface:

Max. floor area	L1	L2	L3
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1218mm, or 48".

Nissan Nissan NV250 roof height:

Roof in millimeters	H1	H2	H3
Interior height (mm)	1251	1252	1154
Exterior height (mm)	1826	1836	1844
Roof in inches	H1	H2	H3
Interior height (inch)	49.3	49.3	45.4
Exterior height (inch)	71.9	72.3	72.6

Wheelbase distance:

Wheelbase	short (SWB)	medium (MWB)
Wheelbase length (mm)	2697	3081
Wheelbase length (inch)	106	121

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x	x	x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Hinged side door measurements

Hinged side door
Door width (mm)
Door height (mm)	1872	1942
Door width (inch)
Door height (inch)	73.7	76.5

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Load floor height:

Height	Metric (mm)	Inches
Minimal loading sill height	588	23.1
Maximum loading sill height	609	24

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	10.7	35.1
Medium wheelbase	11.9	39
Long wheelbase	11.9	39

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	172	6.8
Front overhang	875	34.4
Rear overhang	710	28
Front track	1521	59.9
Rear track	1534	60.4
