CENTIMETERS

• The interior dimensions (length) of the Dodge Sprinter 1 cargo space is 2558mm (L1), 3318mm (L2), and 4278mm (L3).
• The interior width of the is and the exterior width is 1933mm.
• The interior height of the Sprinter 1 is 1651mm (H1), and 1941mm (H2).
• The wheelbase lengths are 3000mm (SWB), 3550mm (MWB), and 4025mm (LWB).
• The width between the wheel arches on this model is 1349mm.

INCHES

• The interior dimensions (length) of the Dodge Sprinter 1 cargo space is 100.7" (L1), 130.6" (L2), and 168.4" (L3).
• The interior width of the is and the exterior width is 76.1".
• The interior height of the Sprinter 1 is 65" (H1), and 76.4" (H2).
• The wheelbase lengths are 118.1" (SWB), 139.8" (MWB), and 158.5" (LWB).
• The width between the wheel arches on this model is 53.1".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Sprinter 1:

Exterior	L1	L2	L3
Exterior length (mm)	4890	1933
Exterior length (inch)	192.5	76.1

All models of the Dodge Sprinter 1 have the same interior and exterior width: 76.1" or 1933mm (exterior).

Interior dimensions of the Sprinter 1:

Inside dimensions	L1	L2	L3
Interior length (mm)	2558	3318	4278
Interior length (inch)	100.7	130.6	168.4

Maximum floor surface:

Max. floor area	L1	L2	L3
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1349mm, or 53.1".

Dodge Sprinter 1 roof height:

Roof in millimeters	H1	H2
Interior height (mm)	1651	1941
Exterior height (mm)	2370
Roof in inches	H1	H2
Interior height (inch)	65	76.4
Exterior height (inch)	93.3

Wheelbase distance:

Wheelbase	short (SWB)	medium (MWB)	long (LWB)
Wheelbase length (mm)	3000	3550	4025
Wheelbase length (inch)	118	140	158

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	1300
Door height (mm)	1519	1821
Door width (inch)	51.2
Door height (inch)	59.8	71.7

Rear doors:

Barn door measurements

Rear barn door	Regular	H2
Door width (mm)	1565
Door height (mm)	1539	1839
Door width (inch)	61.6
Door height (inch)	60.6	72.4

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)	Wall-to-wall (m)	Wall-to-wall (ft)
Short wheelbase	12.8	42	1.2	3.9

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	189	7.4
Front track	1610	63.4
Rear track	1630	64.2

Other resources

• Besides this page, we've also created a resource containing the tightening torque spec settings of the Dodge Sprinter.
