What are the Dimensions for the Chevrolet Astro (1995-2005)?

By IFCAR - Own work., Public Domain

CENTIMETERS

  • The interior dimensions (length) of the Chevrolet Astro 2 cargo space is 3200mm (L1).
  • The interior width of the is and the exterior width is 1969mm.
  • The interior height of the Astro 2 is 1199mm (H1).
  • The wheelbase lengths are 2825mm (SWB).
  • The width between the wheel arches on this model is 1310mm.

INCHES

  • The interior dimensions (length) of the Chevrolet Astro 2 cargo space is 126" (L1).
  • The interior width of the is and the exterior width is 77.5".
  • The interior height of the Astro 2 is 47.2" (H1).
  • The wheelbase lengths are 111.2" (SWB).
  • The width between the wheel arches on this model is 51.6".

Are these dimensions right for you?

Production years: 1995 - 2005 Generation: 2 Type of van: cargo Body style: Panel Also known as: GMC Safari

Dimensions in tables

Outside dimensions of the Astro 2:

Exterior L1
Exterior length (mm) 4821 1969
Exterior length (inch) 189.8 77.5

All models of the Chevrolet Astro 2 have the same interior and exterior width: 77.5" or 1969mm (exterior).

Interior dimensions of the Astro 2:

Inside dimensions L1
Interior length (mm) 3200
Interior length (inch) 126

Maximum floor surface:

Max. floor area L1
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1310mm, or 51.6".

Chevrolet Astro 2 roof height:

Roof in millimeters H1
Interior height (mm) 1199
Exterior height (mm) 1903
Roof in inches H1
Interior height (inch) 47.2
Exterior height (inch) 74.9

Wheelbase distance:

Wheelbase short (SWB)
Wheelbase length (mm) 2825
Wheelbase length (inch) 111

Door measurements:

Available door options:

Side doors Rear doors
Slide Hinged Barn Tailgate
x x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm) 526
Door width (inch)
Door height (inch) 20.7

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Turning circle:

Turning circle Kerb-to-kerb (m) Kerb-to-kerb (ft)
Short wheelbase 12.3 40.4

Miscellaneous dimensions:

Dimension mm inch
Ground clearance unladen 173 6.8
Front track 1654 65.1
Rear track 1654 65.1
