Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the Chevrolet Combo C cargo space is 1787mm (L1).
• The interior width of the is 1348mm and the exterior width is 1684mm.
• The interior height of the Combo C is 1175mm (H1).
• The wheelbase lengths are 2715mm (SWB).
• The width between the wheel arches on this model is 1107mm.

INCHES

• The interior dimensions (length) of the Chevrolet Combo C cargo space is 70.4" (L1).
• The interior width of the is 53.1" and the exterior width is 66.3".
• The interior height of the Combo C is 46.3" (H1).
• The wheelbase lengths are 106.9" (SWB).
• The width between the wheel arches on this model is 43.6".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Combo C:

Exterior	L1	Width
Exterior length (mm)	4322	1684
Exterior length (inch)	170.2	66.3

All models of the Chevrolet Combo C have the same interior and exterior width: 53.1" or 1348mm (interior max); and 66.3" or 1684mm (exterior).

Interior dimensions of the Combo C:

Inside dimensions	L1	Width
Interior length (mm)	1787	1348
Interior length (inch)	70.4	53.1

Maximum floor surface:

Max. floor area	L1
Square meters (m2)	2.4
Square feet (ft2)	25.9

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1107mm, or 43.6".

Chevrolet Combo C roof height:

Roof in millimeters	H1
Interior height (mm)	1175
Exterior height (mm)	1801
Roof in inches	H1
Interior height (inch)	46.3
Exterior height (inch)	70.9

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	2715
Wheelbase length (inch)	107

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x	x	x

Side doors measurements:

Sliding door measurements

Sliding door	Regular
Door width (mm)	620
Door height (mm)	913
Door width (inch)	24.4
Door height (inch)	35.9

Hinged side door measurements

Hinged side door	Regular
Door width (mm)	620
Door height (mm)	913
Door width (inch)	24.4
Door height (inch)	35.9

Rear doors:

Barn door measurements

Rear barn door	Regular
Door width (mm)	1238
Door height (mm)	1139
Door width (inch)	48.7
Door height (inch)	44.8

Load floor height:

Height	Metric (mm)	Inches
Minimal loading sill height	584	23

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)	Wall-to-wall (m)	Wall-to-wall (ft)
Short wheelbase	10.82	35.5	11.25	36.9

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	150	5.9
Front track	1417	55.8
Rear track	1440	56.7
