Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the Honda Odyssey 2 (RL1) cargo space is 2438mm (L1).
• The interior width of the is 1245mm and the exterior width is 1920mm.
• The interior height of the Odyssey 2 (RL1) is 1321mm (H1).
• The wheelbase lengths are 3000mm (SWB).

INCHES

• The interior dimensions (length) of the Honda Odyssey 2 (RL1) cargo space is 96" (L1).
• The interior width of the is 49" and the exterior width is 75.6".
• The interior height of the Odyssey 2 (RL1) is 52" (H1).
• The wheelbase lengths are 118.1" (SWB).

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Odyssey 2 (RL1):

Exterior	L1	Width
Exterior length (mm)	5110	1920
Exterior length (inch)	201.2	75.6

H1=LX Model
H2=EX and EX - L Model

All models of the Honda Odyssey 2 (RL1) have the same interior and exterior width: 49" or 1245mm (interior); and 75.6" or 1920mm (exterior).

Interior dimensions of the Odyssey 2 (RL1):

Inside dimensions	L1	Width
Interior length (mm)	2438	1245
Interior length (inch)	96	49

H1=front
H2=middle
H3=rear

Maximum floor surface:

Max. floor area	L1
Square meters (m2)	3
Square feet (ft2)	32.7

Please note that this is an indication and does not take into account the wheel arches.

Honda Odyssey 2 (RL1) roof height:

Roof in millimeters	H1	H2
Interior height (mm)	1321
Exterior height (mm)	1740	1770
Roof in inches	H1	H2
Interior height (inch)	52
Exterior height (inch)	68.5	69.7

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	3000
Wheelbase length (inch)	118

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate

Side doors measurements:

Rear doors:

Miscellaneous dimensions:

Dimension	mm	inch
Front track	1680	66.1
Rear track	1680	66.1
