Jump to dimension: outside inside surface roof wheelbase doors load height

CENTIMETERS

• The interior dimensions (length) of the GMC Safari 2 cargo space is 3200mm (L1).
• The interior width of the is and the exterior width is 1969mm.
• The interior height of the Safari 2 is 1199mm (H1).
• The wheelbase lengths are 2825mm (SWB).
• The width between the wheel arches on this model is 1310mm.

INCHES

• The interior dimensions (length) of the GMC Safari 2 cargo space is 126" (L1).
• The interior width of the is and the exterior width is 77.5".
• The interior height of the Safari 2 is 47.2" (H1).
• The wheelbase lengths are 111.2" (SWB).
• The width between the wheel arches on this model is 51.6".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Safari 2:

Exterior	L1
Exterior length (mm)	4821	1969
Exterior length (inch)	189.8	77.5

All models of the GMC Safari 2 have the same interior and exterior width: 77.5" or 1969mm (exterior).

Interior dimensions of the Safari 2:

Inside dimensions	L1
Interior length (mm)	3200
Interior length (inch)	126

Maximum floor surface:

Max. floor area	L1
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1310mm, or 51.6".

GMC Safari 2 roof height:

Roof in millimeters	H1
Interior height (mm)	1199
Exterior height (mm)	1903
Roof in inches	H1
Interior height (inch)	47.2
Exterior height (inch)	74.9

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	2825
Wheelbase length (inch)	111

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)	526
Door width (inch)
Door height (inch)	20.7

Rear doors:

Barn door measurements

Rear barn door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Turning circle:

Turning circle	Kerb-to-kerb (m)	Kerb-to-kerb (ft)
Short wheelbase	12.3	40.4

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	173	6.8
Front track	1654	65.1
Rear track	1654	65.1

Other resources

• Besides this page, we've also created a resource containing the tightening torque spec settings of the GMC Safari.
