What are the dimensions of the Mitsubishi Express (2020-on)?
This article will give you detailed information on the Mitsubishi Express; both the internal and external dimensions, the size of the load area, and some general information on the van.
This page will be helpful when you're converting a van into a camper van, or when you're planning the layout for your new corporate van.'
CENTIMETERS
- The interior dimensions (length) of the Mitsubishi Express cargo space is 2537mm (L1), and 2937mm (L2).
- The interior width of the X82 is 1662mm and the exterior width is 2283mm.
- The interior height of the Mitsubishi Express is 1387mm (H1), and 1898mm (H2).
- The wheelbase lengths are 3098mm (SWB), and 3498mm (MWB).
- The width between the wheel arches on this model is 1268mm.
INCHES
- The interior dimensions (length) of the Mitsubishi Express cargo space is 99.9" (L1), and 115.6" (L2).
- The interior width of the X82 is 65.4" and the exterior width is 89.9".
- The interior height of the Mitsubishi Express is 54.6" (H1), and 74.7" (H2).
- The wheelbase lengths are 122" (SWB), and 137.7" (MWB).
- The width between the wheel arches on this model is 49.9".
Dimensions in tables
Outside dimensions of the Express:
| Exterior | L1 | L2 | Width |
|---|---|---|---|
| Exterior length (mm) | 4999 | 5399 | 2283 |
| Exterior length (inch) | 196.8 | 212.6 | 89.9 |
All models of the Mitsubishi Express have the same interior and exterior width: 65.4" or 1662mm (interior); and 89.9" or 2283mm (exterior).
Interior dimensions of the Express:
| Inside dimensions | L1 | L2 | Width |
|---|---|---|---|
| Interior length (mm) | 2537 | 2937 | 1662 |
| Interior length (inch) | 99.9 | 115.6 | 65.4 |
Maximum floor surface:
| Max. floor area | L1 | L2 |
|---|---|---|
| Square meters (m2) | 4.2 | 4.9 |
| Square feet (ft2) | 45.4 | 52.5 |
Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1268mm, or 49.9".
Mitsubishi Express roof height:
| Roof in millimeters | H1 | H2 |
|---|---|---|
| Interior height (mm) | 1387 | 1898 |
| Exterior height (mm) | 1971 | 2465 |
| Roof in inches | H1 | H2 |
| Interior height (inch) | 54.6 | 74.7 |
| Exterior height (inch) | 77.6 | 97 |
Wheelbase distance:
| Wheelbase | short (SWB) | medium (MWB) |
|---|---|---|
| Wheelbase length (mm) | 3098 | 3498 |
| Wheelbase length (inch) | 122 | 138 |
Door measurements:
| Doors | Side door | Rear door |
|---|---|---|
| Door width (mm) | 1030 | 1391 |
| Door height (mm) | 1284 | 1320 |
| Door height H2 (mm) | 1820 | |
| Side door | Rear door | |
| Door width (inch) | 40.6 | 54.8 |
| Door height (inch) | 50.6 | 52 |
| Door height H2 (inch) | 71.7 | |
More Info on Dimensions
If you want to know...
- why there's a difference in exterior and interior width
- what L1 or H3 means
- how to read measurements
- or why dimensions matter
... I encourage you to read my post on how to understand van dimensions.
Can you stand up in a Mitsubishi X82?
Standing up in an empty van
The interior roof height of a Mitsubishi Express is
1387mm (H1) - 1898mm (H2) .
If you are of medium height (178cm or 5"10') you
can't stand up in a Mitsubishi Express H1.
But you can stand up in a Mitsubishi Express H2 and up.
What happens if I insulate the van?
Are you planning on insulating and cladding the floor and roof? In that case you can't stand up fully in a Express H1. But you would still be able to stand up in a H2 model and up.
What's a X82 high top?
Mitsubishi provides their X82s with both high and low tops. High tops are elevated roofs to provide more headroom. Generally, everything above H2 is considered a high top, and should offer sufficient space to stand up fully.
