CENTIMETERS

• The interior dimensions (length) of the Chrysler Chrysler Voyager 3 cargo space is 2195mm (L1).
• The interior width of the is and the exterior width is
• The interior height of the Chrysler Voyager 3 is 1252mm (H1).
• The wheelbase lengths are 2878mm (SWB).
• The width between the wheel arches on this model is 1247mm.

INCHES

• The interior dimensions (length) of the Chrysler Chrysler Voyager 3 cargo space is 86.4" (L1).
• The interior width of the is and the exterior width is
• The interior height of the Chrysler Voyager 3 is 49.3" (H1).
• The wheelbase lengths are 113.3" (SWB).
• The width between the wheel arches on this model is 49.1".

---

Dimensions in tables

Jump to dimension: outside inside surface roof wheelbase doors load height

Outside dimensions of the Chrysler Voyager 3:

Exterior	L1
Exterior length (mm)	4732
Exterior length (inch)	186.3

All models of the Chrysler Chrysler Voyager 3 have the same interior and exterior width: .

Interior dimensions of the Chrysler Voyager 3:

Inside dimensions	L1
Interior length (mm)	2195
Interior length (inch)	86.4

Maximum floor surface:

Max. floor area	L1
Square meters (m2)
Square feet (ft2)

Please note that this is an indication and does not take into account the wheel arches.
The width between the wheel arches on this model is 1247mm, or 49.1".

Chrysler Chrysler Voyager 3 roof height:

Roof in millimeters	H1
Interior height (mm)	1252
Exterior height (mm)	1740
Roof in inches	H1
Interior height (inch)	49.3
Exterior height (inch)	68.5

Wheelbase distance:

Wheelbase	short (SWB)
Wheelbase length (mm)	2878
Wheelbase length (inch)	113

Door measurements:

Available door options:

Side doors		Rear doors
Slide	Hinged	Barn	Tailgate
x		x

Side doors measurements:

Sliding door measurements

Sliding door
Door width (mm)
Door height (mm)
Door width (inch)
Door height (inch)

Rear doors:

Barn door measurements

Rear barn door	Regular
Door width (mm)	1303
Door height (mm)	1031
Door width (inch)	51.3
Door height (inch)	40.6

Miscellaneous dimensions:

Dimension	mm	inch
Ground clearance unladen	137	5.4
Front track	1600	63
Rear track	1626	64
